Description
Pulleys
Classical timing Pilot bore L075
Classical timing Pilot bore L075
PHP 50L075RSB
| No. of teeth | 50 |
| Pitch diameter (mm) | 151.6 |
| Pitch diameter (in) | 5.97 |
| Outside diameter (mm) | 150.84 |
| Outside diameter (in) | 5.94 |
| Pulley type | 5 |
| Min. bore (mm) | 12 |
| Min. bore (in) | 0.47 |
| Max. bore (mm) | 40 |
| Max. bore (in) | 1.57 |
| Flange A (mm) | – |
| Flange A (in) | – |
| H | 60 |
| H (in) | 2.36 |
| F | 25.4 |
| F (in) | 1 |
| L | 35 |
| L (in) | 1.38 |
| Weight (kg) | 2.25 |
| Weight (lbs) | 4.96 |
